Fujitsu fi-7900 scanner
Specifications
Image Sensor Type
Color Charge coupled device (CCD) image sensor (1 front,1 back)
Light Source
White LED Array x 4 (front x2, back x2)
Multifeed Detection
Ultrasonic multi-feed detection sensor, Paper detection sensor
Output Resolution (dpi)
Monochrome, Grayscale and Color
50 – 600 dpi
1200 dpi (driver(2))
Optical Resolution (dpi)
600 dpi
Output Format
Color: 24 bit, Grayscale: 8 bit,
Monochrome: 1 bit
Paper Weight (Thickness)
A4 to A5 Size:5.4 to 56 lb
Less than A5 /Over A4:11 to 56 lb
Image processing functions
Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, De-Screen, Emphasis, Halftone, Dropout color (None /Red /Green /Blue /White / Saturation /Custom), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Cropping, Dither, Static threshold, Divide long page
Paper Chute Capacity
(landscape(3))
500 Sheets (letter, 20 lb.)
ADF minimum
2 in. x 3 in.
ADF maximum
12 in. x 17 in.
Long Document(4)
12 in. x 220 in.
Interface
USB 2.0 / USB 1.1
Letter/Landscape Mode
Simplex/Duplex
Monochrome, Grayscale & Color
@ 200/300 dpi (4)(5)
140 ppm/280 ipm
Letter/Portrait Mode
Simplex/Duplex
Monochrome, Grayscale &
Color @ 200/300 dpi
105 ppm/210 ipm
Power requirements (auto-switching)
AC 100 - 240V +/- 10%
Power consumption
Operating Mode: 200 Watts or less
Sleep mode
Sleep mode: 3.2 Watts or less
Operating environment
Temperature: 41°F - 95°F (5°C - 35°C)
Relative Humidity
20% - 80% (non-condensing)
Dimensions (WxDxH)
18.1 x 16.9 x 12.2 in. (trays closed)
Daily duty cycle
120,000 documents per day*. See Notes 5
Limited Warranty
3 months on-site
Options
Post Imprinter (Back-side and Front-side), PaperStream Capture Pro
Image processing functions
Multi image output, Automatic color detection, Blank page detection, Static threshold, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (Red/Green/Blue/White/Saturation or Custom), sRGB output, Hole punch removal, Cropping, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Character extraction, Background pattern removal, Automatic profile selection
In box Software / Drivers
(on DVD) *software can be downloaded from website designated in the Setup DVD
PaperStream IP driver (TWAIN/TWAIN x64/ISIS), WIA Driver, PaperStream Capture, 2D Barcode for PaperStream, Software Operation Panel, Error Recovery Guide, Scanner Central Admin
Operating System Support
Microsoft® Windows Vista,7, 8,10,11
Microsoft® Windows Server (64 bit only) 2008,2012,2016 and 2019,2022
Part Numbers
fi-7900 – PA03800-B005
