N7100E Scanner Specifications
Scanner Type
ADF, Duplex, Simplex, Color, Grayscale, Bitonal
Resolution
150, 200, 300, 600 dpi (custom 50-600 dpi)
Optical Resolution
600 dpi
Image Sensor Type
Color CIS x 2 (front x 1, back x 1)
Paper Weight (Thickness)
11 to 56 lb
Plastic Cards: .029 or less
Color
24-bit single pass color, auto color detection
Scanning speeds
Color:Simplex: 25 ppm (200dpi), Duplex: 50 ipm (200dpi)
Expected Daily Volume
4,000 sheets
ADF capacity
50 Sheets (letter/A4, 20 lb.)
ADF Min/Max
Min: (2 in. x 2 in.)
Max:(Legal) (8.5 in x 14 in)
(long) (120 in.)
Document Thickness
Paper: 11 lb. to 56 lb.
Plastic Card: 0.029 in. (.76mm) or less
Multifeed Detection
Ultrasonic sensor
Output File Formats
PDF (searchable/password-protected/compressed/
marker index processed), JPEG, TIFF (single/multipage), page output in reverse order
Output methods
Save image data to network folder/SharePoint/FTP
server, Send image data by E-mail, Print*⁵ (Send image data to printer server or network printer),
Send image data by FAX (Send image data to FAX server or internet FAX in E-mail format)
Network Authentication
User: Active directory or Open LDAP (for Solaris or Linux),
Standalone authentication.
Folder: Active Directory or Open LDAP (for Solaris or Linux)
Network Protocols
TCP/IP (IPv4/IPv6), DHCP (IPv4/IPv6), SMTP, SMB, LDAP(S), FTP(S), HTTP(S)
Interface
10BASE-T, 100BASE-TX, 1000BASE-T
Software Driver Support
All software loaded on system (embedded)
Power Consumption
38 W or less, Energy saving mode: 2 W or less Power Off Mode 0.3 W or less
Operating environment
Temperature: 41° to 95° F (5° to 35° C)
Relative humidity
20% to 80% (non-condensing)
Dimensions (HxWxD)
11.8 in. (W) x 9.1 in. (D) x 6.8 in. (H)
Environmental compatibility
RoHs
Automatic image processing
Auto deskew, auto orientation, auto page size detection and blank page detection, color detection
Security
LDAP, LDAPS, FTPS, HTTPS
Display
LCD: 8.4 in. XGA (1,024 x 768 pixels) TFT color monitor
Touch Screen: Analog resistive touch screen (keyboard)
Limited Warranty
One year AUR Limited Warranty. Advance Exchange, Basic, and Depot programs also available; Restrictions apply.
Service Options
Post-Warranty — Advance Exchange, Basic, and Depot programs also available; restrictions apply. Consumables — ScanAid™ kits
Inbox Contents
Scanner, AC cable, AC adapter, LAN cable, Getting Started Guide
