Epson SureColor P20000 Series
60 Inch Large Format Printer
Minimum cut-sheet size:
8.5"x11"
Max Print roll: 64"x590"
Left/Right Margins
3 mm each side; 6 mm or 0.24" total
Top/Bottom Margins, Normal
3 mm/15mm
Top/Bottom Margins,Centering On
15 mm each side
Single Sheet, Top-loading
Single sheets up to 44" Wide
Sheet Loading
Auto-loading if less than 0.5 mm thick
Media Thickness
0.8 mm to 1.5 mm
Roll Paper
60" roll (not included), 2" or 3 "Core
Top/Bottom Margin (mm)
Normal: 20/15; option: 35/15, 150/15, 15/15, 3/3
Left/Right Margins
3 mm each side; 0.24" total; or 0" at supported BorderFree® widths
BorderFree on 2" and 3" Cores
10", 11.8", 13", 16", 17", 20.3", 23", 24", 33", 36", 40.55", 44", 50", 54", 60"
Roll Cutting:
High-speed internal rotary cutter; auto or manual
Minimum auto cut length 5"
printable barcode tracking system for roll paper remaining.
Printing Technology:
Advanced PrecisionCore TFP 10-channel, drop-on-demand printhead with ink-repelling coating technology
Minimum Ink Droplet Size:
Smallest Droplet Size: 3.5 picoliters; Variable Droplet Technology can produce up to three different
dot sizes per line
Maximum Print Resolution:
2400 x 1200 dpi
Print Speed: (averaged)
16" x 20"-from 1:47 to 3:17; Normal- 2:09
20" x 30" -from 2:55 to 5:33; Normal- 3:40
40" x 60" -from 8:33 to 16:30; Normal- 10:52
Nozzle Configuration:
Color and monochrome heads;360 nozzles x 10
Printer Language/Drivers
Epson Professional Photographic Drivers standard; optional internal Adobe® PostScript® 3TM
print server
Operating Systems
Mac® OS X® 10.7.X or later, Windows® 10, 8.1, 8 and 7 (32-bit,64-bit)
Temperature
Operating: 50˚ to 95˚F (10˚ to 35˚C)
Operating (Recommended): 65˚ to 75˚F (18˚ to 24˚C)
Storage: -4˚ to 104˚F (-20˚ to 40˚C)
Humidity:
Operating: 20–80% (no condensation)
Operating (Recommended): 45–60% (no condensation)
Storage: 5–85% (no condensation)
Sound Level:
Operating: Approx 65 dB(A)
Dimensions:
Dimensions: Basket Open: 95.1" x 38.4" x 45.1"
Ink Included:
UltraChrome HD + HDX
110 ml Ink Cartridges
10 Colors: Photo Black, Cyan, Vivid Magenta, Yellow, Light Cyan, Vivid Light Magenta, Dark Gray, Matte Black, Gray, Light Gray
Warranty
Standard 1-year usually next-business-day on-site repair with
toll-free phone support Monday through Friday. Extended warranties are available.
